Installation and piping
We perform installation and piping work using all common connection techniques, especially in the fields of hydraulics and lubrication technology. Our service technicians have many years of experience in the installation, piping and commissioning of hydraulic systems. Equipped with special tools and modern measuring devices, they meet the most demanding of requirements.
Our service range
- Installation and services for hydraulic equipment and lubrication systems
- Commissioning of systems
- Welding technology
- Hydraulic piping
- New hoses
- Piping installation
- On-site consulting
Bending, flanging and forming
Non-standard service
Sometimes standards are there to be consciously circumvented. PHILIPP has the machinery at its disposal to realise extreme bending radii for pipes and high bending angles of up to 150°. You can rely on one thing: our hydraulic team can bend your requirements into shape.Challenge us!
Mobile bending equipment
- Bending of pipes with diameters from 6 to 60 mm
- Bending radii from 2 x D to 3 x D
- For bending angles up to 150°
- Internal and external deburring
- With cutting ring pre-assembly equipment
- Precisely repeatable bending
Mobile double flange F37
- Form-fit 37° flange system for pipes, Pipe outer diameters from 16 to 190 mm and flanges from 1/2 to 6°
- F37 system is compliant with ISO 6164 with SAE-defined hole pattern
- Adjustable 1,000 PSI, 3,000 PSI and 6,000 PSI series
EO2-Form WorkCenter F3
The EO2-Form WorkCenter F3 operates fully automatically. The forming process only involves one-third of the work steps that are necessary in welding, so connections can be easily, quickly and safely made.
- Pipe Ø 6- 42 mm
- Steel and 1.4571 (stainless steel ss316)
- Cycle time: approx. 15-20 seconds
- High-temperature steel
- Easy to install
- Highest resistance to vibration and pressure
- Unbreakable connection
- No welding required
- Fewer possible errors
- Cheaper components
- Lower stock levels
- API 614-compliant
Seals, Pumps and Motors
Pumps and seals
Further services
- Honing
- Grinding
- Nickel plating
- Chrome plating
- Hardening
Seals
- O-rings
- Rod seals
- Strippers
- Grooved rings
- Piston seals
- Ring seals
- Guide elements
- Gear pumps and motors
- Vane pumps and motors
- Axial piston pumps and motors
- Radial piston pumps and motors
All of the above with a constant or variable displacement volume in open or closed circuits. Our primary goal is to ensure your satisfaction by providing an optimal service as well as technically mature and practice-oriented products, and it continues to apply unrestrictedly after you have purchased one of our products.
